Full Hydraulic Cable Drum Trailers 20 Ton

Heavy-Duty 20 Ton Cable Drum Trailer for Large Cable Reels

The Full Hydraulic Cable Drum Trailer 20 Ton is designed for transporting, lifting and unwinding extra-large cable drums on demanding cable installation projects.

With a 20,000 kg payload capacity, the FHCDT-20 is built for heavy cable reels used in power, telecommunications and large infrastructure projects. Its full hydraulic drum lifting and pay-off system provides controlled handling from loading to cable deployment.

The trailer accommodates cable drums up to 4,000 mm in diameter and provides a 2,500 mm clear loading width. A Diesel Antor LD510 engine powers the hydraulic system, while the full air brake system supports safe and controlled transportation.

With a cable opening speed of up to 20 m/min, the FHCDT-20 provides a practical solution for contractors working with large and heavy cable reels.

Your Trusted Partner in Cable Handling Solutions

As one of the leading cable drum trailer manufacturers in Turkey, we take pride in delivering cost-effective, high-performance solutions to clients worldwide. Our products are trusted by industry professionals for their exceptional build quality, safety features, and efficiency.

Key Features

• 20,000 kg payload capacity
• Full hydraulic drum lifting and pay-off
• Maximum drum diameter: 4,000 mm
• Clear loading width: 2,500 mm
• Cable opening speed: 20 m/min
• Diesel Antor LD510 engine
• Full air brake system
• 125 mm drum shaft diameter
• Heavy-duty construction
• 4 heavy-duty tyres
• Designed for large cable installation projects
