Cable laying products – Its preparation and equipment’s used for it
Cables set up into cable pipes are normally used on assignments where the cable pipe is concealed deep inside the ground. This is for providing adequate fortification for the cable pipe and consequently the cables that frequently have a high voltage and are potentially dangerous o not being installed correctly, Cable laying products.
The sort of cables that are regularly set up in such applications requires that several checks be done ahead of proceeding with the cable pull.
Checks that must be done ahead of a cable pull
It is vital that a cable duct line is tested for any impediment and anything found be removed.
To ensure that duct’s of ample size for accommodating the cable.
If, at some stage in such checks, the span of cable, which is 3 meter, incurs any damage over half the deepness of the surface casing the duct route has to be fixed before the pulling through of the entire cable, cable laying products.
There are many a company that supply premium cable laying products
And cable pulling items. Such companies can provide the complete range of items for duct as well as trench applications.
Equipment’s used for installation of cables
Installation of cables usually requires a maximum of 9 diverse cable laying products, which are:
Cable Winch – It’s used for actually heaving the cable right through the duct, lessening the requirement for manpower and adding to productivity.
Cable Bell mouth – Its use is the added defense to the cables while being heaved right through the duct.
Rope Guide Roller – this guide draw ropes/-cabling ropes emerging from joint boxes/ manhole.
Swivel Link – This swivels a complete 360° and lets the pulling through of the rope with no twists
Cable Drum Trailer – It’s of use in the storage and transportation of cable drums.
.
Cable Socks – This supports the heaving thorough of cables.
Conduit Rod – This is of use in installing draw/ winch ropes. /
Manhole Roller – This is helpful in guiding the wire/cable.
Cable Lubricant – It makes the pulling process easier and speedier and puts off snagging and consequently damage to the wire/cable.
What do the producers of such products offer you?
The producers of premium cable laying products have staffs that are present where the operation is in progress and they strive to realize the unique desires and demands of clients.
- Their service stations warranty optimal support for the clients.
- They also offer discount on their products and services and a warranty for their products.
The importance of cable drum rollers
in Cable Laying AccessoriesThe Cable Drum Rollers make rolling cables trouble-free and rapid. Just place the cable drum onto the roller and unwind cables. Cable drum rollers are used for large cable spools, for payout, unwinding & take up of heavy cable.
What are cable drum rollers used for
Cable Drum rollers are one of the most cable rollers that are used for storing and unreeling of Cable reels and rolls. These cable drum rollers comprise of smooth running zinc plated rollers that consist of heavy duty steel ball bearings that ensure easy cable payout without any kind of hassles. Each cable roller has been smartly designed to safely dispense a reel of cable or wire in a smooth and protected manner. An average sized cable roller can secure a roll of cable up to 350 mm wide and the centers of the rollers can also be made in a way so that they can be suited for small as well as big diameter cable reels.
The settings of a cable drum roller
The centers of the cable drum roller comprise of galvanized steel rollers. They are made of rigid and welded steel frame that is powder coated. These cable drum rollers have a safe working load of 200 kgs and are specially designed by well known engineers. Cable drum rollers are used by electricians, technicians, communication people, linesmen and various people all across the nation.
What is Cable drum rollers used for?
Cable drum rollers are usually the most required in narrow trenches and in confined areas where there is very less space. They are very easy to maintain and have a bright zinc plated finish. There are various kinds of cable drum rollers based on the shape, size and requirements. They comprise of straight cable drum rollers, corner cable drum rollers, and triple and special cable rollers. These cable drum rollers are usually used to pull thick and heavy cables into the ground and trenches as well as deep pits. The cables are pulled with the help of the straight cable drum roller that are placed on the cable trench so that the cable is not dragged down into the mud and is damaged. Cable drum rollers are one of the most important equipments in demand by various construction companies.They are made with strong and durable material that will last for long
Cable Drum trailers is it a good choice to make
in Cable Drum TrailersCable Drum Trailers
Cable Drum trailers is it a good choice to make
Introduction:
Cable drum trailers are the most important accessories, which are being used in any kind of project. Whether it is a construction company or electric supply or be it is telecom industry. The cable drum is primarily equipment used for loading and unreeling of cable drums and cable reels at the best possible rate of outcome.
Get the best manufacture:
You should be cleared about the specifications of cable drum trailer. The hydraulic cable drum trailers are very highly formulated, in such a manner that carries most favorable strength. The installation of trailer is done effortlessly. And it is comprise of a long durable life and the loads it can carry for a long time.
The demand of this hydraulic cable drum trailers are very high due to the outstanding performance is well expediency and consistency, cable drum trailers. The leak pins helps in controlling the lifts in case of failure. That cable has a locking system, which helps to hold the cable drums in place while in actions. The manufacturer of the trailer takes care that each and every possible way so that no mishap and all the work get conducted in smooth and efficient manner.
The types of cable drums and their benefits:
The various kinds of cable drums, which are available according per customers, need. It is initially required on different sites and on some of site projects. The variety of drum trailers, among which CD 20, PT60 and CD30, which are very commonly used in so many The cables are ready that have got breaking and as well as road lighting system cable drum trailers.
The system is intended in such a manner that it carries out heavy loads and it travels up with a good speed. With the built in hydraulic hand pumps the trailer is safe while travelling even on smooth roads. For further protection it also comprises of mechanical security. They are engineered in such manners that it gets fitted with the most powerful and heavy-duty engines. The performances are hassle free and provide good hydraulic transmission for a smooth pull.
Overall View:
The most vital point you should get hold is about the quality of the product and conviction, dependability and superiority of goods is being sold. The equipment’s are safe for usage and government certified, with 2years warranty. It is easy to maintain and the spare parts are cheap and services are of low cost.
Cable Pulling Machines – An Useful Equipment For You
in Cable Pulling MachinesCable Pulling Machines – An Useful Equipment For You
Cable pulling machines are one of the premium quality equipment’s. It is not only reliable and efficient for the purpose and it provide the best cost effective method of laying about all cables to come in the upcoming years.
These cables are durable as well as long lasting in nature, and it is safe for usage. Some of these cables are made out as per you requirements and is being customized accordingly.
The essential part of cable pulling machines are the cable drums as it helps all the units to accommodate all tasks together which are heavy and non movable by one self. They help to carry out the works as it got the best quality hard copper cables, which are very hard to move from one part to another. These cable pulling machines are generally used in various projects both onsite and offsite.
Specifications:
The cable-pulling machine consists a power unit with diesel engine rated from 13Kw to 3600rpm. It also consists of a main drive system with a single capstan. Hydraulic driven rope tension with rewind drums drive. It also contains dial gauge for pressure pull with a pull load indicator.
The diameter of the rewind drum states from 400mtrs x 10mm with maximum capacity. The rope laying is a free moving laying arm, which is mounted under the rewind drum.
Benefits of using the Cable pulling machines:
Cable Pulling Winches Covered Version
The manufacturer makes sure that the cable pulling machines are capable of carrying out various sizes of drums with the help of cable wire. It comprises of a vast number of hydraulic and cable machines that helps out in smooth work flow and takes care about the performance as well. The equipment’s are all the upgraded versions with the latest technology and it is definitely focused on the best materials.
Take a good look before getting your hands on any materials:
You should gather up your knowledge before you end up purchasing any Cable pulling machines. Get to know about the manufacturer, see their selling details and also the reliability. Check the safety and the quality of the product. The warranty period is valued for long good 2years. Also go through the maintenance options and the services the company provides with the availability of cheap parts.
Capstan Winch and its working methodology
in Cable Pulling MachinesCapstan Winch and its working methodology
Capstan winch is a new development in the winch invention and has a lot to offer to the users. Winches these days are used almost everywhere starting from the entertainment to the sports and of course not to forget the commercial and construction industry. You must remember to know about your work needs and specifications before you buy a winch because it is important to know which winch will suit you and can take the weight of your work with no added manual labor.
Working Of A Capstan Winch
The invention of Capstan winches has definitely added power to the cable pulling machines. These winches come in all kinds of shapes and sizes and are cost friendly. It also gives the customer consumer satisfaction as our products are made of the very best quality and we extend our services to our buyers ever after the product is bought and is in use. These winches mainly work on hydraulic power and has an engine internally built. It is most commonly used to pull up or lay underground cable lines and requires almost no manual power. It ensures a smooth running and functioning of the work. It also works with a double capstan to ensure smooth speed and control of the same. Spare parts are also easily and readily available. We offer only best quality products.
Features
With strength and durability, the other features that you should consider and look at while buying a capstan winch are its pulling abilities. It can pull a tough wire like copper wire and set it up along with lightweight wires. No electrical power or manual force is needed to work these winches. It works smoothly and is eco friendly along with cost effectiveness. It improves the efficiency of work and is also able to reduce the speed if it exceeds the limit. All the winches are crafted with care and are only brought into the market to be sold after careful supervision and demonstration. We believe in giving the best products to our customers as it helps to build trust and customer satisfaction.
The designs are specially made to suit the client’s needs and demands. All are made tough, durable and long lasting along with stylish touches under excellent craftsmanship. It is made in a way to withstand all conditions that it may face. It has the advantage of averting mishaps as it is hydraulically controlled and are sound proof and lockable. They come with safety measures that can also be used on trailers and come with a guarantee of two years.
Get To Know About Capstan Winches
in Cable Pulling MachinesGet To Know About Capstan Winches
Winches are used in working of many machines these days including cable pulling machines and small boats. With growing demand, winches have improved over time with many-advanced mechanism. Capstan Winches are such an improvement and also an addition to the family of winches. Before you buy one you need to know the specifications of capstan winches.
About Capstan Winches
Capstan is a vertical-axle rotating machine that was developed over time to be used on ships and sailing boats to apply force to rope, cables and hawsers. Capstan winches were developed on the same mechanism for the use of cable pulling machines. Winches play an important part in the working of cable pulling machines and helps applying force in pulling up of cables and also installing them. These winches receive power either from electricity or hydraulically.
Services Offered
The invention of Capstan winches has definitely added power to the cable pulling machines. These winches come in all kinds of shapes and sizes and are cost friendly. It also gives the customer consumer satisfaction as our products are made of the very best quality and we extend our services to our buyers ever after the product is bought and is in use. These winches mainly work on hydraulic power and has an engine internally built. It is most commonly used to pull up or lay underground cable lines and requires almost no manual power. It ensures a smooth running and functioning of the work. With long lasting and durable services the capstan winches sure makes an important improvement in cable pulling machines. A rope guide is provided for the perfect laying of rope or cables as winches are mostly used for cable pulling machines these days. Also easy to maintain.
Cable Pulling Winches – a few information that you did not know before
in Cable Pulling MachinesCable Pulling Winches
Cable Pulling Winches – a few information that you did not know before
Cable pulling machines are in hot demand now a days for increasing the efficiency of work and also making it easy to lay down cable lines in no time at all. Cable pulling winches is an inseparable part of cable pulling machines. Winches are mostly used in pulling heavy load automobiles like trucks, trailers etc. It is important to note that although we have a lot of mechanized way of working these days, the cable pulling winches are interdependent upon each other for working out.
What are Cable Pulling Winches?
Winches are small in nature and are applied in all industries including the entertainment and sports industry. Winches have become an integral part of all commercial working industries. It features a small gasoline engine in the four-cycle design, clutches and the spool, all of which lies inside a frame made of steel. The winch mechanism works when the pull is made to stop and it takes the entire load with minimum operation tension and this kind of mechanism is mostly found in small sailing boats, cable pulling winches.
Types of Winches
There are many types of winches like Hydraulic winch, Glider winch, cable pulling winches. Each winch has some specialty and all the products come with a two-year guarantee. Experts offer the post buying services and any technical difficulty faced is taken care of with utmost importance by our technical experts. The Glider Winch is mainly used for the purpose of launching gliders on heavier automobiles. It is cost friendly and the mechanism works on hydraulic fluids. We also offer higher standards of winches in accordance with your needs. There are three questions related to winches that you should look into while purchasing a winch that are if the winch is powerful, portable and light in weight. The technical specifications of a winch are also another matter of importance that should be considered and looked into while purchasing a winch. The working and effectiveness of the winch depends upon the work and the winch you choose for the same. We guarantee commodity satisfaction along with unhindered services.
Cable laying products – Its preparation and equipment’s used for it
in Cable Pulling MachinesCable laying products – Its preparation and equipment’s used for it
Cables set up into cable pipes are normally used on assignments where the cable pipe is concealed deep inside the ground. This is for providing adequate fortification for the cable pipe and consequently the cables that frequently have a high voltage and are potentially dangerous o not being installed correctly, Cable laying products.
The sort of cables that are regularly set up in such applications requires that several checks be done ahead of proceeding with the cable pull.
Checks that must be done ahead of a cable pull
It is vital that a cable duct line is tested for any impediment and anything found be removed.
To ensure that duct’s of ample size for accommodating the cable.
If, at some stage in such checks, the span of cable, which is 3 meter, incurs any damage over half the deepness of the surface casing the duct route has to be fixed before the pulling through of the entire cable, cable laying products.
There are many a company that supply premium cable laying products
And cable pulling items. Such companies can provide the complete range of items for duct as well as trench applications.
Equipment’s used for installation of cables
Installation of cables usually requires a maximum of 9 diverse cable laying products, which are:
Cable Winch – It’s used for actually heaving the cable right through the duct, lessening the requirement for manpower and adding to productivity.
Cable Bell mouth – Its use is the added defense to the cables while being heaved right through the duct.
Rope Guide Roller – this guide draw ropes/-cabling ropes emerging from joint boxes/ manhole.
Swivel Link – This swivels a complete 360° and lets the pulling through of the rope with no twists
Cable Drum Trailer – It’s of use in the storage and transportation of cable drums.
.
Cable Socks – This supports the heaving thorough of cables.
Conduit Rod – This is of use in installing draw/ winch ropes. /
Manhole Roller – This is helpful in guiding the wire/cable.
Cable Lubricant – It makes the pulling process easier and speedier and puts off snagging and consequently damage to the wire/cable.
What do the producers of such products offer you?
The producers of premium cable laying products have staffs that are present where the operation is in progress and they strive to realize the unique desires and demands of clients.
What Is a Cable Drum Trailer?
in Cable Drum TrailersWhat Is a Cable Drum Trailer?
A machine cannot work alone if not supported by a support system that is either another machine or a person or a programme. Cable pulling machines also need the support of cable drum trailer also more commonly known as the cable laying equipment. It is useful equipment as mostly it is used in supporting the cable-pulling machine while installing cable lines overhead or underground.
As the name suggests, a trailer is basically a car that trails behind and is connected to the machine to make the operations handier and also to carry the machine over long distances. It is important to note the trailer size and the machine size so that both can work without and hindrance. Using a trailer also takes care of extra safety measures and the operator gets a better working opportunity. It is cost effective and safe to use, cable drum trailer.
Types Of Cable Drum Trailers
There are two types of Cable drum trailers- the Highway Range and the Site Range. Both types are much in demand these days with the growing need of lying down of cable lines. The Highway Range is well equipped with braking and road lightning systems, which in turn also conforms to EEC directives. Designed to travel heavily loaded along all the UK roadways and other European countries, these also come in variations to maintain county requirements. Cable Drum Tariler, These drum trailers are also fitted with standardized hydraulic hand pump operated lifting and lowering systems.
It makes drum handling safe and easy and the mechanical locks also ensure drum security in transit when the drum is raised. The other Range that is the Site Range drum trailer that is mainly used off road and is fitted with braking system, hand parking facility and some vehicle lights. This range sometimes also has some additional features like that of the Highway Range. It can take up a maximum payload of 48,000kgs. All safety measures are looked into and all machines come with a guarantee of two years, cable drum trailer.
What are cable drum stands used for
in Cable Drum TrailersWhat are cable drum stands used for
Cable drum stands are available in a number of different sizes. They are available in small as well as big sizes. They are very useful for industrial purposes and project work. Read on to know more about cable drum stands.
Why are the cable drum stands used?
Cable drum stands are usually used for mounting cable drums on the deck of an elevating work platform or small utility work. They can also be directly mounted onto the ground for work. The drum stands are manufactured from the steel box section and are painted black. They are provided with 4 holes in the base for fixing to a motor vehicle and are supplied with spindle and accessories. The spindles are locked in place with the aid of pins and each spindle is provided with lifting lugs at each end. All spindle hardware is zinc plated and gold plated as well. You can also choose between small drum stands and big drum stands.
Specifications of drum stands
The maximum diameter of a drum stand is around 800mm. The maximum drum width is around 600mm and the maximum weight is around 150kg. The drum stand designs are improved on a regular basis. The bigger drums stands have been specifically designed for hot dip galvanized frame and 54 mm steel spindle. The spindles are provided with disc brake as standard. The stands are provided with four lifting points. The spindle rotates on sealed bearings, which are free from maintenance. They are provided with forklift apertures, which make it possible to lift the drum, stand from any side with a forklift. All drum stands can be provided with a wide range of options including power rotations and a separate power pack. Drum stands are provided with special link pins that connect the multiple drums stands all together.
The best apparatus to be used
The cable drum stands capable of producing a line pull of 10kn while paying out overhead Power Lines and 30mtrs/min Recovery speed. Installing overhead power cables are easy with the help of two drum stands by placing one on top of the other Cable drum stands have a warranty of two years and they are easily maintainable as well. They are affordable and come in various budgets.
The efficacy of cable drum stands
in Cable Drum TrailersThe efficacy of cable drum stands
Cable drum stands have been specifically designed to meet the needs of contractors and project workers where the necessity of having a cable drum trailer is not practical. These are very useful and efficient when concerned with the project workers and contractors.
How are the cable drum stands designed?
Cable drum stands are available with either a fixed spindle, i.e. a drum loaded by the external means or supplied self sufficiently for lifting or lowering as used on a standard Cable Drum trailer. They are available in Diesel, petrol, PTO drum drive system or electric system for easy cable payout. The drum stands are mounted with turntable, which allows for 360 degrees of axis movement for total suppleness when solid mounted. These drum stands have been designed and manufactured to suit the requirements of the client.
Specifications of the cable drum stands
A normal drum diameter is 1800 mm with the width of 1500 mm. The maximum drum width is 2.5 tones and the drum speed is 30 mars/minute. The drum stand has been powered by diesel engine contained in weatherproof cabinet with sound proofing as well. They are manually operated by hydraulic controls and remote control options are also available.
Built to your specifications
Cable drum stands can be built as per your specifications for using conveniently with vehicles. They have been specially designed with a one-man operated spindle shaft that can be interchanged with a self-loading cable trailer when needed. The cable drum stand has a hydraulically adjusted height roller, which allows for usage with different shapes and sizes of drums. The drum can be built as per the customer’s specification with its own Power engine. They are capable of producing a line pull of 10kn while paying out overhead Power Lines and 30mtrs/min Recovery speed. Installing overhead power cables are easy with the help of two drum stands by placing one on top of the other Cable drum stands have a warranty of two years and they are easily maintainable as well.
